Designed to be a powerful unit, the Solution 2.3 insert offers a surprising quality of combustion. Every detail is thoughtfully planned to optimize its performance, which far exceeds the latest industry standards.
Many of its features are identical to its freestanding counterpart. Strategically positioned, a powerful heat-activated fan (144 CFM) allows an optimal redistribution of the heat produced by the firebox in the room. In addition, its design allows it to receive a faceplate whose dimensions can cover a masonry hearth with a maximum height of 32 inches and width of 50 inches. Designed for those looking for an eco-friendly and efficient stove; the best of both worlds!
APPROVED FOR THE ISLAND OF MONTREAL.
Features
- Recommended heating area: 500 to 2,100 sq. ft.
- Firebox volume: 2.4 cu. ft.
- Maximum heat output (dry cordwood): 75,000 BTU/h
- Maximum log length: 20”
- Exterior dimensions (excluding faceplate): 28 5/8” W x 27” D x 22 7/8” H
- Minimum hearth dimensions (masonry opening): 28 7/8” W x 15 3/4” D x 23 5/16” H
- Combustion technology: Non-catalytic
- Included: 144 CFM blower with variable speed control
Specification
| Combustion technology | Non-catalytic |
| Maximum burn time | 8 h |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 20" |
| Log positioning | Loading over width |
| Chimney diameter | 6" |
| Flue outlet diameter | 6" |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height (feet) | 12' |
| Approved for a mobile home installation | No |
| Baffle type | C-Cast or equivalent |
| Shipping Weight | 456 lb (207 kg) |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 16 5/8" X 10 5/8" |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 144 |
| Overall dimension (Height) | 22 7/8" |
| Overall dimension (Width) | 28 5/8" |
| Overall dimension (Depth) | 27" |
| Door opening – dimension (Height) | 9 3/4" |
| Door opening – dimension (Width) | 17 1/2" |
| Firebox – dimension (Height) | 11 7/8" |
| Firebox – dimension (Width) | 21" |
| Firebox – dimension (Depth) | 16 1/2" |
| Firebox lined with refractory bricks for better heat distribution | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Steel thickness – body | 3/16" |
| Steel thickness – top | 3/8" |
| USA standard (emissions) | EPA |
| Fireplace opening – minimum (Height) | 23 3/8" |
| Fireplace opening – minimum (Width) | 28 7/8" |
| Fireplace opening – minimum (Depth) | 15 3/4" |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S628 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
Appliance Performance
| Fuel type | Dry cordwood (16" recommended) |
| Recommended heating area-ft² |
500 - 2,100 |
| Overall firebox volume-ft³ | 2.4 |
| EPA loading volume-ft³ | 1.95 |
| Maximum heat output-dry cordwood | 75,000 BTU/h (22.0 kW) |
| Overall heat output rate < | 14,200 BTU/h (4.16 kW) to 44,500 BTU/h (13.04 kW) |
| Average overall efficiency (dry cordwood) |
72 % (High Heating Value) 77 % (Low Heating Value)) |
| Optimum overall efficiency | 79 % |
| Optimum heat transfer efficiency | 76 % |
| Average particulate emissions rate | 2.3 g/h |
| Average CO | 69 g/h |
Documents & Files
- Wood Products Brochure
- Wood stove | Safety notifications & general information
- Solution 2.3-I wood insert installation & operation requirements
- Solution 2.3-I dimensions
